Screw End Lock 3D print model

This module allows the user to lock 2 rows of base plates in place so that they will not be sliding freely.

This module allows the user to fix the grid to the surface through screws.

There are 4 screw holes for mounting.

What information you will get in the download folder:

• Grid instruction manual
• 3D print Recommendations
• Bar colour information

Here are the module’s dimensions in millimetres:

• H 16mm
• L 50mm
• B 37mm

Screw holes diameter:

• 5mm

Please have a look on my profile to see all the other modules.

The grid allows you to organise your work environment.
