Drafting Expert CADEx Studio

Draw Points To AutoCADThis plugin will make your drafting life easy and faster.DescriptionDo you have data points in an Excel file that you want to import into AutoCAD?Do you have data points in an CAD file that you want to import into Excel or csv?By CADEx Studio you can draw a million points in one click.COORDINATE is a program that allows you to export and import or draw the coordinates values of the objects present in the drawing. The objects for which it is possible to extract coordinate values are:-points-circles (center)-blocks (insertion point).

Coordinate values will refer to the current UCS.The program draws coordinates in 3 ways:

• as multiline texts, you can configure the color, height, and position
• as blocks, coordinate values are placed in the block's attributes.Through the dialogue box, it is possible to select whether to number the coordinates, which coordinates to draw (X, Y or Z), and their color.It is also possible to choose the number of decimal digits to be displayed and choose whether to insert additional points in each vertex of the selected objects.The export of coordinates to file can be done in different formats..xls CSV text file in which data is separated by commas.Once CADEx Studio Excel program is working try to close other CAD files except which CAD wants to export and import. The plugin is for permanent and multi-user. Buy once and use forever. This program will work for all AutoCAD and Civil 3D versions (2009 to 2025)
