This 3D model was originally created with Sketchup 8 and then converted to all other 3D formats. Native format is .skp 3dsmax scene is 3ds Max 2016 version, rendered with Vray 3.00 Data Center Room with Isolation caps and plastic doors for cold isle isolation, ladder rack etc. Raised floor tiles are based on 610cm x 610cm (2' x 2'). Cabinets are basic 610cm x 1220cm (2' x 4'). Ladder rack is based on 300cm width. I have made a power-point showing the cost savings information regarding this projects design on www.noaccess.com/~dsweeney/misc.html follow the link to the power point.
It seems that others have copied and resubmitted this drawing.. THIS IS THE ORIGINAL.Dan
