Solar Panel Steel Construction Type 14

Solar Panel Steel Construction Type 14 3D model

Description

Solar Panel Steel Construction Type 14

4x12 Horizontal Panel Layout

Ground Connection Type; With Concrete Friction Pile

Distance of Columns Below Ground 1500 mm.

Concrete Friction Pile Dimensions : Ø300 mm H= 1800 mm

Panel Dimensions : 2279 x 1134 x 35 mm

Panel Power : 550Wp

1 solar panel steel construction produces 26,4 kWp power in 1 hour

The system consists of 11 axles and the distance between each axle is 2600 mm.

Distance between two columns 2300 mm.

Horizantal angle of panel 25°

The closest distance of the panels to the floor 600 mm.

Profile Section;

Column : C Profile C100x50x20-3mm Beam : C Profile CE120x50x20_25°-3mm Purlin : C Profile C70x40x15x-2mm Diagonal : U Profile U50x30-2mm

Prepared With BLENDER Version 2.93.5

Polygons : 364356

Vertices : 433406

Objects : 631
