1 Inch BSP - Union elbow 90 degrees F x M - Autodesk Inventor 3D model
Description
Metal union elbow 90 degrees 1 Inch BSP for Autodesk InventorFree 3D CAD model:
- Description: Threaded union elbow 90 degrees
- Diameter: 1"
- Material: Metal (stainless steel)
- Connection: BSP female x BSP male
- File format: Autodesk Inventor .ipt
You can use this CAD model directly in:■ Autodesk Inventor 2015■ Autodesk Inventor 2016■ Autodesk Inventor 2017
This is a sample CAD model from the full range library BSP threaded metal fittings and valves. This Content Center library for Autodesk Inventor contains many hundreds premium quality 3D piping parts for mechanical engineers.Click here for all details about this library.
I hope you can use this CAD model in one of your engineering projects. Feel free to share, like or comment...
Freerk de With, Wyalo 3D CAD models
1 Inch BSP - Union elbow 90 degrees F x M - Autodesk Inventor
Royalty Free License
1 Inch BSP - Union elbow 90 degrees F x M - Autodesk Inventor
Royalty Free License
3D Modeling
3D Model formats
Format limitations
Native
- Autodesk Inventor (.iam, .ipt)392 KB
Exchange
3D Model details
- Publish date2016-04-18
- Model ID#313913
- Animated
- Rigged
- VR / AR / Low-poly
- PBR
- Geometry Other
- Polygons 0
- Vertices 0
- Textures
- Materials
- UV Mapping
- Unwrapped UVs
- Plugins used
- Ready for 3D Printing
