IEC80 B5 - Electric motor

IEC80 B5 - Electric motor 3D model

Description

IEC Three phase asynchronous AC motor.
Frame size 80 - 2-8 Pole Frame type B5 (Flange mount)

Power range 80 IEC motors (50Hz): 0,75-1,1kW - 3000 r.p.m. / 0,55-0,75kW - 1500 r.p.m. / 0,37-0,55kW - 1000 r.p.m.
This free 3D CAD model is a sample from the full range (21 parts) 3D CAD library

File formats: ■ Autodesk Inventor .ipt ■ STEP (.stp) file format, for direct import in: - Autodesk Inventor - Autodesk Fusion 360 - Dassault Solidworks - Dassault Catia - Siemens Solid Edge - ISMI Turbocad Professional ■ Autocad (.dwg) ■ DATASHEET in pdf file format is included!

I hope you can use the 3D models! Freerk de With Wyalo 3D CAD models
