High-Speed Canning and Cartoning Machine 3D model

This industrial 3D model represents an automatic high-speed canning machine, designed for efficient and precise carton packaging. The process consists of four key stages: carton opening, product filling, capping, and final sealing, ensuring smooth and accurate packaging. The machine utilizes dual-motor-driven cam mechanisms to perform synchronized actions with high precision, making it ideal for industries such as pharmaceuticals, cosmetics, automotive parts, and food packaging.

Key Features & Specifications:

Fully Automated Operation – Handles carton opening, product filling, and sealing with minimal manual intervention.High-Speed Performance – Achieves a production capacity of 50-120 boxes per minute, optimizing efficiency.Advanced Carton Handling – Ensures precise alignment, secure capping, and strong latch insertion for reliable packaging.Versatile Application – Suitable for round bottles, aluminum-plastic sheet blocks, toothpaste, and more.Detailed 3D Model – Includes over 1400 parts, featuring technical drawings, part assemblies, and total assembly diagrams.Power & Air Requirements – Operates on a three-phase AC380V power supply, with an output of 2.5 kW and gas consumption of 20 m³/h at 0.5-0.8 MPa.Robust Build – Weighs approximately 1.2 tons, ensuring stability and durability for industrial applications.

This comprehensive 3D model serves as a valuable resource for engineers, manufacturers, and automation experts, facilitating machine analysis, production optimization, and design modifications for seamless high-speed canning operations.
