Automatic Depalletizer Pallet Warehouse 3D model

Automatic Depalletizer Pallet Warehouse

Introduction

A device for automatically removing pallets (pallets), which can also be used for stacking and collecting empty pallets; instead of manual frequent placement of empty pallets, it cooperates with automatic palletizing equipment to reduce manual operations; the pallet adopts a pneumatic lifting mechanism, and the guide column and Guided by linear bearings, the operation is stable; empty pallets are transported using a chain mechanism, which saves costs; the process and structure are simple, easy to operate and control.

File Formats

• SolidWorks 2018 | Keyshot 10
• STEP (Standard for the Exchange of Product Data)
• IGES (Initial Graphics Exchange Specification)
• STL (Standard Tessellation Language )
• OBJ (Object Files)

Geometry

• Polygons: 846,586
• Vertice: 2,539,758
