Parametric shelf 02 Design filesfor cnc cutting 3D model

Parametric shelf 02 Design for Home Office and interiors digital download DXF files vector template, wooden furniture ,laser cutting chair.

DIGITAL DOWNLOAD

MODEL NAME : parametric shelf 02

(READY TO CUT FILES, NO ADDITIONAL EDITING REQUIRED) All the parts are nested with minimum 12mm clearance part to part gap

MATERIAL : 15mm wood plywood or any other hard material. Total 72 pieces to be cut.

(Two sheets of 4ft x 8ft are needed for the design as shown in the image above)

DIMENSIONS : 2160mm x 450mm x 610mm L x W x H.

Support structure Dimensions

1 : 25mm x 25mm x 2170mm 2 : 25mm x 25mm x 1400mm

HOW TO ASSEMBLE:

• All parts are numbered accordingly to make assembly simple and easy.

• the support wood structure dimension are provided in the design.

• Assemble all the parts and fasten with screws at the back.

*after assembly fix it on the wall using screws on the support structure.
