Steel Pedestrian Bridge Type-32 3D model

Steel Pedestrian Bridge- Type.32

Pedestrian Overpass With Flat Type Ramp

Closed Top Construction

Two Column Type

Open Top Construction

Named Objects

Largest Column Span : 30 mt.

Distance Between Two Columns : 30 mt.

Platform Asphalt Height : 6 mt.

Platform Width : 3 mt.

Straight Type Ramp

Ramp Width : 1,8 mt.

Ramp Lenght : 51 mt.

Column Foundation Concrete : width 2,5 mt * length 6 mt. * height 1 mt.

Ramp Foundation Concrete : width 1 mt * length 2,5 mt. * height 1 mt.

Flat Railing Construction

Railings Box Profile

Platform And Columns With Bolted Connection

Walking Surface : 6 mm. Patterned Plate

Prepared With BLENDER Version 2.93.5

All Model

Polygons : 124818

Vertices : 229054

Objects : 5585

Steel Model Only

Polygons : 122725

Vertices : 225316

Objects : 5173
