Description

Steel Pedestrian Bridge

Truss Type Platform Construction

Three Column Consruction

Open Top Construction

Straigth Beam Type

Straight Column Type

Named Objects

Largest Column Span : 40,8 mt.

Distance Between Two Columns : 20,4 mt.

Platform Asphalt Height : 6 mt.

Platform Width : 3 mt.

Platfrom Truss Heigth : 3 mt.

Column Raft Concrete : width 2,5 mt * length 6 mt. * height 1 mt.

Spiral Stair Raft Concrete : width 2,5 mt * length 2,5 mt. * height 1 mt.

Spiral Stair Type

Stair Step Width : 1,657 mt.

Step Sizes : 50/565 mm. * 150 mm.

Flat Railing Construction

Railings Box Profile

Platform And Columns With Bolted Connection

Walking Surface : 2 cm. Rubber Flooring

Prepared With BLENDER Version 2.93.5

Polygons : 117070

Vertices : 187460

Objects : 3817
