Steel Pedestrian Bridge
Sailing Column Type Construction
Two Column Consruction
Open Top Construction
Straigth Beam Type
Curved Column Type
Platfrom With Steel Rope Tensioning System
Named Objects
Largest Column Span : 48,74 mt.
Distance Between Two Columns : 48,74 mt.
Platform Asphalt Height : 6 mt.
Platform Width : 3 mt.
Steel Rope : 16 piece
Rope Fixed Press : 16 piece
Rope Tensioning Press System : 16 Piece
Column Raft Concrete : width 2,5 mt * length 6 mt. * height 1 mt.
Stairs Raft Concrete : width 1 mt * length 2,5 mt. * height 1 mt.
Tension Column Raft Concrete : width 2,5 mt * length 2,5 mt. * height 1 mt.
Stairs Straight Type
Stair Step Width : 1,8 mt.
Step Sizes : 300 mm. * 150 mm.
Flat Railing Construction
Railings Box Profile
Platform And Columns With Bolted Connection
Walking Surface : 2 cm. Rubber Flooring
Prepared With BLENDER Version 2.93.5
Polygons : 156950
Vertices : 255328
Objects : 3812
