Steel Pedestrian Bridge

Sailing Column Type Construction

Two Column Consruction

Open Top Construction

Straigth Beam Type

Curved Column Type

Platfrom With Steel Rope Tensioning System

Named Objects

Largest Column Span : 48,74 mt.

Distance Between Two Columns : 48,74 mt.

Platform Asphalt Height : 6 mt.

Platform Width : 3 mt.

Elevator Steel Construction And Composite Coating

Elevator : width 2,25 mt * length 2,25 mt. * height 12,5 mt.

Elevator Cabin : not prepared

Steel Rope : 16 piece

Rope Fixed Press : 16 piece

Rope Tensioning Press System : 16 Piece

Column Raft Concrete : width 2,5 mt * length 6 mt. * height 1 mt.

Spiral Stair Raft Concrete : width 2,5 mt * length 2,5 mt. * height 1 mt.

Tension Column Raft Concrete : width 2,5 mt * length 2,5 mt. * height 1 mt.

Elevator Raft Concrete : width 2,5 mt * length 2,5 mt. * height 1,5 mt.

Spiral Stair Type

Stair Step Width : 1,657 mt.

Step Sizes : 50/565 mm. * 150 mm.

Flat Railing Construction

Railings Box Profile

Platform And Columns With Bolted Connection

Walking Surface : 2 cm. Rubber Flooring

Prepared With BLENDER Version 2.93.5

Polygons : 164503

Vertices : 263642

Objects : 3971
