3 MW Solar Project Type 14 3D model
Description
2,89 MW Solar Project Type 14
Static Steel Fabrication Project
2x10 Vertical Panel Layout
Ground Connection Type; Steel Driven Column
Distance of Columns Below Ground 900 mm.
Panel Dimensions : 2279 x 1134 x 35 mm
Panel Power : 550Wp
1 solar panel steel construction produces 11 kWp power in 1 hour
The system consists of 5 axles and the distance between each axle is 2500 mm.
Distance between two columns 2500 mm.
Horizantal angle of panel 20°
The closest distance of the panels to the floor 700 mm.
Prepared With AutoCAD Version 2021
3 MW Solar Project Type 14
Royalty Free License
3 MW Solar Project Type 14
Royalty Free License
3D Modeling
3D Model formats
Format limitations
Native
- AutoCAD 2010 (.dwg)1.26 MB
Exchange
- PDF (.pdf)778 KB
- DXF 2010 (.dxf)8.34 MB
3D Model details
- Ready for 3D Printing
- Animated
- Rigged
- VR / AR / Low-poly
- PBR
- Geometry -
- Polygons 0
- Vertices 0
- Textures
- Materials
- UV Mapping
- Unwrapped UVs Unknown
- Plugins used
- Publish date2023-07-27
- Model ID#4666309
