22 mt Pedestrian Bridge 3D model

22 mt. Pedestrian Bridge

Galvanized Steel and Black Painting Steel

Two Column Consruction

Open Top Construction

Straigth Beam Type

Straight Column Type

Named Objects

Largest Column Span : 22 mt.

Distance Between Two Columns : 22 mt.

Platform Asphalt Height : 6 mt.

Platform Width : 3 mt.

Column Raft Concrete : width 2 mt * length 6 mt. * height 1 mt.

Stairs Raft Concrete : width 1 mt * length 2,2 mt. * height 1 mt.

Stairs Straight Type

Stair Step Width : 1,5 mt.

Step Sizes : 300 mm. * 150 mm.

Flat Railing Construction

Railings Box Profile

Platform And Columns With Bolted Connection

Walking Surface : 5 mm. Floor Sheet

Prepared With BLENDER Version 2.93.5

All Models;

Polygons : 709831

Vertices : 829312

Objects : 2793

Prepared With BLENDER Version 2.93.5

Only Ground Model;

Polygons : 1769

Vertices : 2988

Objects : 285

Prepared With BLENDER Version 2.93.5

Only Bridge Model;

Polygons : 708062

Vertices : 826324

Objects : 2508
